RACKS & CABINETS

Engineered for precision, durability, and performance in every environment.

Applications

  • Electrical switchgear & control panels
  • Data centers & telecom
  • Industrial automation systems
  • Food & pharmaceutical industries
  • Commercial buildings
  • Harsh environmental applications

Key Features

  • Manufactured from Grade 304 / 316L stainless steel
  • Excellent corrosion and impact resistance
  • IP55 / IP65 / IP66 protection
  • Smooth finish for easy cleaning & hygiene
  • Suitable for indoor & outdoor environments

Customization Options

  • Cut-outs & knock-outs for cable entry
  • Special sizes on request
  • Powder coating / polishing finishes
  • Window doors with tempered glass
  • Cooling / ventilation systems
  • Multiple locking options

Part Numbers

316L Enclosure Part Numbers
S.No Part Number H W D No. of Gland Plate
1 PRC-316L-202015 200 200 150 1
2 PRC-316L-252015 250 200 150 1
3 PRC-316L-252515 250 250 150 1
4 PRC-316L-302015 300 200 150 1
5 PRC-316L-302515 300 250 150 1
6 PRC-316L-302520 300 250 200 1
7 PRC-316L-303015 300 300 150 1
8 PRC-316L-303020 300 300 200 1
9 PRC-316L-402520 400 250 200 1
10 PRC-316L-403015 400 300 150 1
11 PRC-316L-403020 400 300 200 1
12 PRC-316L-404015 400 400 150 1
13 PRC-316L-404020 400 400 200 1
14 PRC-316L-404025 400 400 250 1
15 PRC-316L-406015 400 600 150 2
16 PRC-316L-406020 400 600 200 1
17 PRC-316L-406025 400 600 250 1
18 PRC-316L-406030 400 600 300 1
19 PRC-316L-504015 500 400 150 1
20 PRC-316L-504020 500 400 200 1
21 PRC-316L-504025 500 400 250 1
22 PRC-316L-504030 500 400 300 1
23 PRC-316L-505015 500 500 150 2
24 PRC-316L-505020 500 500 200 1
25 PRC-316L-505025 500 500 250 1
26 PRC-316L-505030 500 500 300 1
27 PRC-316L-604015 600 400 150 1
28 PRC-316L-604020 600 400 200 1
29 PRC-316L-604025 600 400 250 1
30 PRC-316L-604030 600 400 300 1
31 PRC-316L-605015 600 500 150 2
32 PRC-316L-605020 600 500 200 1
33 PRC-316L-605025 600 500 250 1
34 PRC-316L-605030 600 500 300 1
35 PRC-316L-606015 600 600 150 2
36 PRC-316L-606020 600 600 200 1
37 PRC-316L-606025 600 600 250 1
38 PRC-316L-606030 600 600 300 1
39 PRC-316L-705015 700 500 150 1
40 PRC-316L-705020 700 500 200 1
41 PRC-316L-705025 700 500 250 1
42 PRC-316L-705030 700 500 300 2
43 PRC-316L-706015 700 600 150 1
44 PRC-316L-706020 700 600 200 1
45 PRC-316L-706025 700 600 250 1
46 PRC-316L-706030 700 600 300 2
47 PRC-316L-707015 700 700 150 1
48 PRC-316L-707020 700 700 200 1
49 PRC-316L-707025 700 700 250 1
50 PRC-316L-707030 700 700 300 1
51 PRC-316L-804015 800 400 150 1
52 PRC-316L-804020 800 400 200 1
53 PRC-316L-804025 800 400 250 1
54 PRC-316L-804030 800 400 300 1
55 PRC-316L-806015 800 600 150 2
56 PRC-316L-806020 800 600 200 1
57 PRC-316L-806025 800 600 250 1
58 PRC-316L-806030 800 600 300 1
59 PRC-316L-806040 800 600 400 1
60 PRC-316L-808015 800 800 150 2
61 PRC-316L-808020 800 800 200 2
62 PRC-316L-808025 800 800 250 2
63 PRC-316L-808030 800 800 300 2
64 PRC-316L-104015 1000 400 150 2
65 PRC-316L-106015 1000 600 150 2
66 PRC-316L-106020 1000 600 200 2
67 PRC-316L-106025 1000 600 250 2
68 PRC-316L-106030 1000 600 300 2
69 PRC-316L-106040 1000 600 400 2
70 PRC-316L-108015 1000 800 150 2
71 PRC-316L-108020 1000 800 200 2
72 PRC-316L-108025 1000 800 250 2
73 PRC-316L-108030 1000 800 300 2
74 PRC-316L-108040 1000 800 400 2
75 PRC-316L-101025 1000 1000 250 2
76 PRC-316L-101030 1000 1000 300 2
304L Enclosure Part Numbers
S.No Part Number H W D No. of Gland Plate
1 PRC-304L-202015 200 200 150 1
2 PRC-304L-252015 250 200 150 1
3 PRC-304L-252515 250 250 150 1
4 PRC-304L-302015 300 200 150 1
5 PRC-304L-302515 300 250 150 1
6 PRC-304L-302520 300 250 200 1
7 PRC-304L-303015 300 300 150 1
8 PRC-304L-303020 300 300 200 1
9 PRC-304L-402520 400 250 200 1
10 PRC-304L-403015 400 300 150 1
11 PRC-304L-403020 400 300 200 1
12 PRC-304L-404015 400 400 150 1
13 PRC-304L-404020 400 400 200 1
14 PRC-304L-404025 400 400 250 1
15 PRC-304L-406015 400 600 150 2
16 PRC-304L-406020 400 600 200 1
17 PRC-304L-406025 400 600 250 1
18 PRC-304L-406030 400 600 300 1
19 PRC-304L-504015 500 400 150 1
20 PRC-304L-504020 500 400 200 1
21 PRC-304L-504025 500 400 250 1
22 PRC-304L-504030 500 400 300 1
23 PRC-304L-505015 500 500 150 2
24 PRC-304L-505020 500 500 200 1
25 PRC-304L-505025 500 500 250 1
26 PRC-304L-505030 500 500 300 1
27 PRC-304L-604015 600 400 150 1
28 PRC-304L-604020 600 400 200 1
29 PRC-304L-604025 600 400 250 1
30 PRC-304L-604030 600 400 300 1
31 PRC-304L-605015 600 500 150 2
32 PRC-304L-605020 600 500 200 1
33 PRC-304L-605025 600 500 250 1
34 PRC-304L-605030 600 500 300 1
35 PRC-304L-606015 600 600 150 2
36 PRC-304L-606020 600 600 200 1
37 PRC-304L-606025 600 600 250 1
38 PRC-304L-606030 600 600 300 1
39 PRC-304L-705015 700 500 150 1
40 PRC-304L-705020 700 500 200 1
41 PRC-304L-705025 700 500 250 1
42 PRC-304L-705030 700 500 300 2
43 PRC-304L-706015 700 600 150 1
44 PRC-304L-706020 700 600 200 1
45 PRC-304L-706025 700 600 250 1
46 PRC-304L-706030 700 600 300 2
47 PRC-304L-707015 700 700 150 1
48 PRC-304L-707020 700 700 200 1
49 PRC-304L-707025 700 700 250 1
50 PRC-304L-707030 700 700 300 1
51 PRC-304L-804015 800 400 150 1
52 PRC-304L-804020 800 400 200 1
53 PRC-304L-804025 800 400 250 1
54 PRC-304L-804030 800 400 300 1
55 PRC-304L-806015 800 600 150 2
56 PRC-304L-806020 800 600 200 1
57 PRC-304L-806025 800 600 250 1
58 PRC-304L-806030 800 600 300 1
59 PRC-304L-806040 800 600 400 1
60 PRC-304L-808015 800 800 150 2
61 PRC-304L-808020 800 800 200 2
62 PRC-304L-808025 800 800 250 2
63 PRC-304L-808030 800 800 300 2
64 PRC-304L-104015 1000 400 150 2
65 PRC-304L-106015 1000 600 150 2
66 PRC-304L-106020 1000 600 200 2
67 PRC-304L-106025 1000 600 250 2
68 PRC-304L-106030 1000 600 300 2
69 PRC-304L-106040 1000 600 400 2
70 PRC-304L-108015 1000 800 150 2
71 PRC-304L-108020 1000 800 200 2
72 PRC-304L-108025 1000 800 250 2
73 PRC-304L-108030 1000 800 300 2
74 PRC-304L-108040 1000 800 400 2
75 PRC-304L-101025 1000 1000 250 2
76 PRC-304L-101030 1000 1000 300 2
